DC DRIVE

DC DRIVE Manufacturer

SERVO TECH CONTROL SYSTEM designs, manufactures, and supplies high-performance Single Phase SCR-Based DC Drives engineered for precision motor speed control and heavy-duty industrial automation. Built with high-grade copper conductors, robust power electronics, and an industrial-grade powder-coated steel enclosure, our DC motor controllers deliver smooth torque, continuous DC output, and dependable operation across demanding manufacturing environments.

Whether managing conveyor systems, industrial pumps, process blowers, or automated machinery, SERVO TECH CONTROL SYSTEM delivers compact, panel-mounted DC drive solutions with high electrical efficiency and multi-tier protection.

KEY FEATURES AND TECHNICAL HIGHLIGHTS

Precise SCR-Based Speed Regulation

Employs solid-state silicon controlled rectifier (SCR) commutation to deliver an accurate 10:1 speed control range with voltage stability and load regulation held strictly within plus or minus 1 percent.

High Efficiency with Low Ripple

Engineered for minimum power loss with efficiency ratings at or above 85 percent and DC ripple kept strictly below 1 percent, preventing motor overheating and extending armature life.

Comprehensive Electrical Protection

Integrated safety circuitry guards against overload, short circuit, overvoltage, and undervoltage conditions to prevent motor damage and operational downtime.

Flexible Dual-Mode Control

Configured for convenient local control using integrated start and stop push buttons, with built-in terminals for remote relay or PLC integration.

Compact Panel-Mount Enclosure

Enclosed in a rugged, powder-coated steel chassis measuring 190 mm x 120 mm x 100 mm and weighing approximately 3 kg, tailored for clean integration into standard automation control panels.

PRIMARY INDUSTRIAL APPLICATIONS

* Textile and Yarn Processing Equipment

* Conveyor and Material Handling Systems

* Extrusion and Plastic Processing Machinery

* Industrial Packaging and Printing Presses

* Centrifugal and Positive Displacement Pumps

* Exhaust Fans and Industrial Air Handling Blowers

* General Purpose DC Shunt and Permanent Magnet Motor Drives

Primary Supply Locations: Gujarat (Ahmedabad, Surat, Vadodara, Rajkot), Maharashtra (Mumbai, Pune, Nashik), Rajasthan (Jaipur, Bhiwadi), Madhya Pradesh (Indore, Bhopal), and Pan-India Industrial Hubs

FREQUENTLY ASKED QUESTIONS (FAQS)

Q: What makes SERVO TECH CONTROL SYSTEM DC drives suitable for industrial motor speed control?

A: Our drives incorporate advanced SCR-based commutation circuitry with pure copper conductors, delivering continuous variable DC output from 0 to 180V DC with less than 1 percent ripple and plus or minus 1 percent voltage stability. This ensures steady torque delivery, eliminates cogging at low speeds, and optimizes overall energy efficiency to 85 percent or higher.

Q: How is the DC drive installed inside a control panel?

A: The unit features a compact 190 mm x 120 mm x 100 mm footprint designed specifically for backplate or panel mounting. It mounts securely inside standard industrial control panels using the pre-drilled chassis mounting slots, leaving adequate clearance for airflow within the ambient operating range of 0 to 50 deg C.

Q: Can this DC drive be controlled remotely via PLC or automated panel switches?

A: Yes. In addition to local push-button start and stop controls, the terminal block includes dedicated connection points for external switches, relays, or PLC digital outputs for centralized automated control.

Q: What built-in safety protections are included with this drive?

A: The drive provides multi-layer protection covering short circuits, sustained overloads, excessive input voltage surges (overvoltage), and hazardous line drops (undervoltage).

Q: Which geographical areas does SERVO TECH CONTROL SYSTEM supply?

A: We manufacture and supply industrial DC drives across India, with primary domestic distribution and express technical support across Gujarat, Maharashtra, Rajasthan, and Madhya Pradesh. Standard orders carry a minimum order quantity of 1 piece with prompt regional dispatch.
